HeatStar High Intensity Radiant Workshop Gas Heater

Download Manual

MODEL HS25N Natural Gas, Model HS22L Liquid Propane.

This HeatStar Radiant Heater is 99.9% fuel efficient. Whether you choose to use it in your garage to keep your cars warm, your shop to keep the work force busy and comfortable, or in a poultry house egg-room, the Heatstar radiant heater transfers almost all of the fuel it burns directly into clean safe radiant heat. Utilizing a unique power pile thermocouple to control the valve, there is no electricity required. Just hook-up the included millivolt thermostat with the appropriate wire (not included) then mount the heater to the wall ad make the gas connection.

Clearance from Combustibles Top 14″, Side 16″, Back 16″, Below 48″

Must be installed by licensed contractor.

• 25,000 BTU Natural Gas
• 22,000 BTU Liquid Propane
• Heats up to 500-600 Sq Ft
• For use in buildings with 7 to 8 ft ceilings
• Efficient infrared heat that directly heats people and objects which in turn heats surrounding air to desired temperature
• Includes adjustable thermostat for individually controlled warmth and all necessary
• Includes brackets and hardware
• No electricity required, no moving parts to service and easy to install
• Quiet, clean and odor free operation
• Non-corrosive materials used throughout construction
• Gas Inlet 1/2
• Weight: 21 Lbs
• Product Dimensions: 30.75″L x 14.25″W x 10″H
• Warranty: 1 Year Limited for gas control & 5 Year Limited for burner

**Thermostatically controlled
