Patio Heater Parts

Infratech Regulators

Controllers for W-Series heaters

Infratech 120 or 240 Single INF 10/20 Regulator (Switch Only) $54.00	Infratech 120 or 240 Single INF 10/20 Regulator in SS Plated Box $99.00  (only for use UP TO 15 amps)
Infratech 120 or 240 Single INF 10/20 Regulators flush mount  $116.00 *Outside weather proof (only for use UP TO 15 amps)	Infratech 120 or 240 Single INF 10/20 Regulators surface mount $125.00   *Outside weather proof (only for use UP TO 15 amps)
Infratech 120 or 240 Single INF 10/20 Regulators also in SS Plated Dual Gang Box $167.00    (only for use UP TO 15 amps per switch)	Infratech 120 or 240 Single INF 10/20 Regulators flush mount $169.00   *Outside weather proof (only for use UP TO 15 amps)
Infratech 120 or 240 Single INF 10/20 Regulators surface mount $205.00   *Outside weather proof (only for use UP TO 15 amps)

Infratech Switches

Dual Switch Controllers

Infratech Single Duplex Switch with Stainless Steel Wall Plate $104.00 Single Gang in wall Flush mount Indoor (for dual element heaters) Single Gang in wall Flush mount Indoor (for dual element heaters) - See more at: https://www.gasoutdoorpatioheaters.com/electric_heaters.htm#sthash.jbbEdIh0.dpuf	Infratech Single Duplex Switch in Flush Mount Style $115.00 Dual Gang In wall Flush mount Covered (for dual element heaters)
Infratech Single Duplex Switch in Surface Mount Style $134.00 Weatherproof cover Single Gang Outdoor Surface mount (for dual element heaters)	Infratech Dual Duplex Switch with Stainless Steel Wall Plate $167.00 Dual Gang Flush mount Indoor (for dual element heaters) Dual Gang Flush mount Indoor (for dual element heaters) - See more at: https://www.gasoutdoorpatioheaters.com/electric_heaters.htm#sthash.jbbEdIh0.dpuf
Infratech Dual Duplex Switch in Flush Mount Style $179.00 Dual Gang In wall - Outdoor, Weather proof Flush mount (for dual element heaters)	Infratech Dual Duplex Switch in Surface Mount Style $206.00  Dual Gang Surface - Outdoor, Weather proof mount (for dual element heaters)

Infratech Switches

Must buy analog box (Step 1) and analog control (Step 2) together

Step 1 Custom Solid-state analog box multiple-zone control panels in 1,2,3,4,5,6 Zone Please Call 1-800-549-5077 For Help Simple, Cost Effective Input Regulators From $999.00 to $2659.00   https://www.gasoutdoorpatioheaters.com/infratech-heaters Step 2 Low Voltage Remote Heater Control Systems*
Zone Remote Analog Control With Timer in 1,2,3 Zone (Please Call to Order) Please Call 1-800-549-5077 For Help From $665.00 to $989.00 *Will interface with most home management systems	Zone Remote Analog Control in 1,2,3,4 Zone (Please Call to Order) Please Call 1-800-549-5077 For Help From $519.00 to $1015.00 *Will interface with most home management systems

• Commercial design and performance
• Heavy duty steel body with decorative cast iron base
• Fixed or mobile positioning
• Heats up to 29 square meters (290 sq. ft)
• Easy self assembly
• $0.36* per hour to operate compared with approx $1.00/hour for propane (based on electricity cost of $0.15/KW hour)
• Ideal for open terraces, patios etc
• Can be exposed to all outdoor elements (snow / wind / rain)


  The Riviera is a wall mount unit, ideal for Home Patios, Garden Areas Gazebos and
  Awnings. The Capri is a stand mount unit, ideal for large Open Air Terraces in
  Restaurants, Clubs and Pubs.


Model	Price
Solaria Riviera/Capri	$2,899

The Solaira Variable Heat Controller is a weatherproof, digital, solid-state power control designed to provide a convenient way to adjust heat output on electric infrared heating elements. It allows for adjusting heat output of the appliance from 10 to 100% of the available power. The control is simple and intuitive with the on/off switch that will turn the heater on to the last power setting when it was turn off and the "SOFT START" feature will bring the power up slowly to the emitter adding an estimated 15% to the emitter life. The up/down controls are simple to use and the heater level is shown on the LED front panel.



WEATHER PROOF

The Solaira Variable Heat Controller is engineered for installation in both indoor or outdoor applications including wet environments. The controller can be used to control heaters on outdoor applications including patios, outdoor structures and pergolas as well as all indoor applications.



POWER SOURCE

The controller is designed to control the following heating configurations:
208- 240 VAC up to 3200 Watt, Quartz Emitter (lamp) OR Tube technology

DETAILS

• Part# SMRTV60240
• On/Off switch
• Controllable heat settings from 10 to 100%.
• Wall or post mounted, requires a 4"x 4" electrical wall box would mount
• Accommodates standard 1/2" conduit hardware
• Controller will operate
  - One (1) or two (2) quartz lamps totaling up to 3200W at 208 to 240VAC
  - One (1) or two (2) quartz tubes totaling up to 3200W VAC

Model	Price
Variable Heat Controller	$658.00

Caution: All quartz lamps have a high en-rush that can be as high as 15 times the steady state current. For this reason, the maximum number of appliances is two (2) of up to1600W at 208/240V. Any higher wattages could damage the control.

---

Solaira Occupancy Motion Controller



SMaRT Occupancy Monitor Controller for Solaira

For outdoor or indoor applications, Built in user settable temperature, SPE-1000 listed.

• Occupancy Monitoring

• Temperature monitoring

• Soft Start Technology

• Water Resistant Enclosure Design


Solaira SMaRT passive infrared controller is designed to be used with infrared heaters or other heating and lighting products. These models have a built in passive Infrared sensor allowing the heaters to automatically switch on only when patrons or company is detected.





Model	Price
Occupancy Motion Controller	$288.00

---

Solaira Occupancy Motion Sensor



Solaira Occupancy (Motion) Sensor

• Operating voltage: 12Volt dc
• Detect Angle: 90 degrees
• Range to: 50 feet (18meters)

Based on people in the space, the heaters turn on and off automatically with the Salaira Occupancy Monitor Controller.

When the Solaira Occupancy Motion Controller is equipped with the optional Occupancy Monitor, the heaters are switched on for a user-settable time period of between 5 and 60 minutes.



Model	Price
Solaria Riviera	$158.00

---

Solaira Water Proof  Timer Control

SMaRT Solaira Timer

• Soft Start Technology
• Water Resistant Enclosure Design
• Engineered feature extends emitter life by up to 30%
• Push button 1- 60 Minute Timer
• User settable 1 – 60 minute time increment
• Offers energy savings for Infrared Heaters when there is no one in the zone
•  Control up to 6.0kW Infrared Heaters
• 4 and 6 kW Options provide flexible installation Options

SMaRT 40 and 60 Push Button Timer
SPE-1000 listed

• Installation of the unit is simple and once our solid state controller is installed it is relatively maintenance-free.
  The mini controller  unit incorporates zero-voltage switching and a soft-start function.
• The heaters are switched on for a user-settable time period of between 5 and 60 minutes.

Enclosure/Protection Rating:	UL94 certified
Resin Enclosure:	IP65 Water Proof for outdoor/indoor use
Certifications:	CETL SPE-1000, CE

Part #	Voltage	Max Heater Watt	Load
SMRTTIM40	208-230V	4.0kW	16.6 A
SMRTTIM60	208-230V	6.0kW	25 A

Model	Price
Solaria Riviera	$238.00

---

Solaira IR Handheld Remote





SMaRT Handheld Solaira IR Remote

For use with only the Solaira SMaRT Digital Variable Controller. An IR Remote is a convenient
way to manage electric infrared heaters.



• IR signal reaches up to 30 feet
• Handheld
• For outdoor or indoor applications
• Operating voltage: 12Volt dc

Model	Price
Solaria Riviera	$97.00



---

Solaira Post for Alpha High Output Quartz Radiant Infrared Heaters
Permanent Mount for outdoor or indoor area's

Electric Access and watertight fittings

Heat Controllers





The Fostoria VHC-32 Variable Heat Controller is a solid-state phase angle power control designed to provide a convenient way to adjust heat output on electric infrared heating elements.

• Designed to operate Quartz Lamp or Quartz Tube Heating Elements up to a maximum of 3200 watts
• 208/240 VAC single-phase, single stage controller
