Infratech In Wall Duplex/Stack Switches For Indoor Or Protected Outdoor Areas

Starts at: $120.00

Order total:

Application(s):

Brand:

Heater Type:

SKU: N/A Categories: ,

Infratech Duplex/Stack Switches

Infratech’s Duplex Stack Switches offer user-friendly operation that’s compatible with any budget. Choose from different configurations, including In-Wall or Surface Mount options, available with or without weatherproof covers. Can control WD or CD series.

14 4300 Dimensions and Features:

  • Gang Box: 4″ h x 2 1/8″ w x 1 7/8″ d
  • SS Plate: 4 7/8″ h x 3 1/8″ w
  • Two Single Pole Single Throw (DPST) Switches
  • Range: 120/277 VAC
  • Recommended not to exceed:
  • 208/220 VAC = 3000 Watts Max per Switch
  • 240/277 VAC = 4000 Watt Max per Switch
  • 20 Amps Max per Pole
  • Made in the USA
  • 3 Year Warranty

14 4305 Dimensions and Features:

  • Gang Box: 4″ h x 4″ w x 1 9/16″ d
  • SS Plate: 4 7/8″ h x 4 15/16″ w
  • (2) Two Single Pole Single Throw (DPST) Switches, a total of 4
  • Range: 120/277 VAC
  • Recommended not to exceed:
  • 208/220 VAC = 3000 Watts Max per Switch
  • 240/277 VAC = 4000 Watts Max per Switch
  • 20 Amps Max per Pole
  • Made in the USA
  • 3 Year Warranty

Additional information

Choose Model

14 4300 Single Duplex Switch Wall Plate & Gang Box 20Amp Per Pole, 14 4305 Dual Duplex Switch Wall Plate & Gang Box 20Amp Per Pole
